With years of development, AMITY CARE occupies an important position in the Other Material Handling Equipment industry now. We are always in strict accordance with the international quality standards and quality management system, totally ensuring the product quality. 1000kg electric drum pour trolley lifter for coin attaches great importance to technological innovation in the research and development process. TAIZHOU AMITYCARE INTERNATIONAL CO.,LTD always stick to the core value of 'integrity and honesty' since established. We will strive forward to manufacture and provide the fine-quality products and try hard to provide the best services for our customers.

Condition:NewApplicable Industries:drum lifter
Showroom Location:NoneVideo outgoing-inspection:Provided
Machinery Test Report:ProvidedMarketing Type:Hot Product 2019
Warranty of core components:1 YearCore Components:Motor
Place of Origin:Jiangsu, ChinaBrand Name:amitycare
Warranty:1 YearAfter-sales Service Provided:No overseas service provided, Field installation, commissioning and training
Power type:Electric PowerLoading Capacity:1600 (kg)
Tire:Pneumatic TyreMast:Lift Mast
Weight:650kgApplication:warehouse, supermarkets, railway stations, airports ect
Product Name:china hydraulic hand full electric 300kg drum pallet truckOverall size:1800*1000*2000mm
After Warranty Service:Video technical support, Online supportLocal Service Location:None



Product Description



 Model

COT0316ZD

COT0516ZD

COT0520ZD

COT0525ZD

COT0530ZD

Order Number

9.01001

9.01002

9.01003

9.01004

9.01005

Load Capacit (kg)

300

500

500

500

500

Max Lift height(mm)

1600

1600

2000

2500

3000

Minheight of clamp(mm

540

540

540

540

540

Drum size (mm)

φ580 *900

φ580 *900

φ580 *900

φ580 *900

φ580 *900

Drum rotation (mm)

180

180

180

180

180

Battery(V/Ah)

24/80

24/80

24/80

24/80

24/80

Charger (V/A)

24/15

24/15

24/15

24/15

24/15

Lifting motor (Kw)

2.5

2.5

2.5

2.5

2.5

Driving motor (Kw)

0.75

0.75

0.75

0.75

0.75

Weight  (Kg)

490

510

520

530

540

Overall size L*W*H

1800*1000*2000

1800*1000*2000

1800*1000*1580

1800*1000*1780

1800*1000*2050

 Driving wheel(mm)

1*¢200*70

Training wheels(mm)

2*¢150*50

Front wheels (mm)

4*¢80*70

Climbing slope (%)

4/6

Channelrequest1900Turn,1100ForwardandBackward

Travel speed

4/6 Km/h

Lifting speed

45/50 mm/s

Falling speed

45/40 mm/s

Braking type

Electromagenetic braking




1:Full electric stacker are wide used to moving and pouring materials in printing,food and chemical

  industry. AC electric controller assembly.

2:There is power light which shows the condition of power.

3:Durable lead-acid battery can work Continuously for a long time.

4:Strong and stable driving system.

5:Lifting pump with the parts of DC motor,valve and pipe element in one.They are small volume,stable

  performance,noiseless,environment friendly.

6:Supplier offer charger,which can give hints automatically when charging is completed.

7:Noiseless PU Wheels will not scratch the floor.

Packaging & Shipping



Company Profile

Taizhou amity care international co.,ltd is regarded as the foreign trade department of Taizhou xurui

machinery manufacturing co;, all abroad (overseas) tasks and international businesswill be

undertaken by "amity care ".

We Focus on Pallet stacker, Paper Roll Lifter, pallet truck, Electric floor crane, stacker truck ,

drum lifter,car mover,tow tractor,trolley crane ect,we have imported overseas countries
